6 Column

The Ultraheat Column radiators are practical and versatile, making them the perfect choice for any room at home or office. You can choose from either two columns, three, four or six positioning them either vertically from floor to ceiling or tucking one effortlessly under a window.

• 5-Year Warranty
• Available in 17 size options
• High-quality white powder coat finish (White RAL 9016)
• Available in any RAL colour
• Vertical columns (each one with six sections)
• Built to last: 1.5mm thick mild steel for guaranteed quality
• Tested to BS EB 442 Standards
• ISO9001:2008 Registered Manufactured
• We recommend pipework is not installed until receipt of radiator
• All prices are exclusive of VAT and delivery

SKU: 6 Column Categories: 6 Column, Range, Tubular Where to buy

The Range

Max Working Pressure 6 Bars

95 DEGREES MAX WORKING TEMP.

Closed System

Mild Steel

VERTICAL MOUNTING

5 YEARS WARRANTY

SAP CODE	PRODUCT NAME	HEIGHT (mm)	LENGTH (mm)	DEPTH(mm)	FUEL OPTIONS	TOWEL GAPS	PIPES/SECTIONS	HEAT OUTPUT (BTU)	HEAT OUTPUT (WATTS)	WATER CONTENT (L)	GROSS WEIGHT (KG)	FINISH	RRP
	C6030919R	300	864	220	H	N/A	19	4282	1254	21.7	37.5	Other Solid Matt RAL	£920.63
	C6030919T	300	864	220	H	N/A	19	4282	1254	21.7	37.5	Metallic Micrograin Matt Paint	£1,031.11
C6030919-W	C6030919W	300	864	220	H	N/A	19	4282	1254	21.7	37.5	White RAL 9016	£571.82
	C6031125R	300	1130	220	H	N/A	25	5635	1650	28.5	48.5	Other Solid Matt RAL	£1,211.56
	C6031125T	300	1130	220	H	N/A	25	5635	1650	28.5	48.5	Metallic Micrograin Matt Paint	£1,356.95
C6031125-W	C6031125W	300	1130	220	H	N/A	25	5635	1650	28.5	48.5	White RAL 9016	£752.52
	C6031632R	300	1440	220	H	N/A	32	7212	2112	36.5	61.4	Other Solid Matt RAL	£1,727.25
	C6031632T	300	1440	220	H	N/A	32	7212	2112	36.5	61.4	Metallic Micrograin Matt Paint	£1,934.52
C6031632-W	C6031632W	300	1440	220	H	N/A	32	7212	2112	36.5	61.4	White RAL 9016	£1,072.83
	C6031636R	300	1617	220	H	N/A	36	8114	2376	41	68.7	Other Solid Matt RAL	£1,902.83
	C6031636T	300	1617	220	H	N/A	36	8114	2376	41	68.7	Metallic Micrograin Matt Paint	£2,131.17
C6031636-W	C6031636W	300	1617	221	H	N/A	36	8114	2376	41	68.7	White RAL 9016	£1,181.88
	C6050409R	500	421	220	H	N/A	9	3350	981	14.5	27.6	Other Solid Matt RAL	£534.03
	C6050409T	500	421	220	H	N/A	9	3350	981	14.5	27.6	Metallic Micrograin Matt Paint	£598.12
C6050409-W	C6050409W	500	421	220	H	N/A	9	3350	981	14.5	27.6	White RAL 9016	£331.70
	C6050613R	500	598	220	H	N/A	13	4839	1417	21	39.9	Other Solid Matt RAL	£771.89
	C6050613T	500	598	220	H	N/A	13	4839	1417	21	39.9	Metallic Micrograin Matt Paint	£864.52
C6050613-W	C6050613W	500	598	220	H	N/A	13	4839	1417	21	39.9	White RAL 9016	£479.43
	C6050716R	500	731	220	H	N/A	16	5956	1744	25.8	49.1	Other Solid Matt RAL	£949.46
	C6050716T	500	731	220	H	N/A	16	5956	1744	25.8	49.1	Metallic Micrograin Matt Paint	£1,063.40
C6050716-W	C6050716W	500	731	220	H	N/A	16	5956	1744	25.8	49.1	White RAL 9016	£589.73
	C6050919R	500	864	220	H	N/A	19	7072	2071	30.6	58.3	Other Solid Matt RAL	£1,127.69
	C6050919T	500	864	220	H	N/A	19	7072	2071	30.6	58.3	Metallic Micrograin Matt Paint	£1,263.02
C6050919-W	C6050919W	500	864	220	H	N/A	19	7072	2071	30.6	58.3	White RAL 9016	£700.43
	C6051225R	500	1130	220	H	N/A	25	9306	2725	40.3	76.8	Other Solid Matt RAL	£1,483.50
	C6051225T	500	1130	220	H	N/A	25	9306	2725	40.3	76.8	Metallic Micrograin Matt Paint	£1,661.51
C6051225-W	C6051225W	500	1130	220	H	N/A	25	9306	2725	40.3	76.8	White RAL 9016	£921.43
	C6051636R	500	1617	220	H	N/A	36	13400	3924	57.4	110.5	Other Solid Matt RAL	£2,116.47
	C6051636T	500	1617	220	H	N/A	36	13400	3924	57.4	110.5	Metallic Micrograin Matt Paint	£2,370.45
C6051636-W	C6051636W	500	1617	220	H	N/A	36	13400	3924	57.4	110.5	White RAL 9016	£1,314.58
	C6060409R	600	421	220	H	N/A	9	3996	1170	17.4	33.2	Other Solid Matt RAL	£534.03
	C6060409T	600	421	220	H	N/A	9	3996	1170	17.4	33.2	Metallic Micrograin Matt Paint	£598.12
C6060409-W	C6060409W	600	421	220	H	N/A	9	3996	1170	17.4	33.2	White RAL 9016	£331.70
	C6060613R	600	598	220	H	N/A	13	5771	1690	25.2	47.9	Other Solid Matt RAL	£771.89
	C6060613T	600	598	220	H	N/A	13	5771	1690	25.2	47.9	Metallic Micrograin Matt Paint	£864.52
C6060613-W	C6060613W	600	598	220	H	N/A	13	5771	1690	25.2	47.9	White RAL 9016	£479.43
	C6060716R	600	731	220	H	N/A	16	7103	2080	31	58.9	Other Solid Matt RAL	£949.46
	C6060716T	600	731	220	H	N/A	16	7103	2080	31	58.9	Metallic Micrograin Matt Paint	£1,063.40
C6060716-W	C6060716W	600	731	220	H	N/A	16	7103	2080	31	58.9	White RAL 9016	£589.73
	C6060919R	600	864	220	H	N/A	19	8435	2470	36.8	70	Other Solid Matt RAL	£1,127.69
	C6060919T	600	864	220	H	N/A	19	8435	2470	36.8	70	Metallic Micrograin Matt Paint	£1,263.02
C6060919-W	C6060919W	600	864	220	H	N/A	19	8435	2470	36.8	70	White RAL 9016	£700.43
	C6060922R	600	997	220	H	N/A	22	9767	2860	48.4	81	Other Solid Matt RAL	£1,305.75
	C6060922T	600	997	220	H	N/A	22	9767	2860	48.4	81	Metallic Micrograin Matt Paint	£1,462.44
C6060922-W	C6060922W	600	997	220	H	N/A	22	9767	2860	48.4	81	White RAL 9016	£811.03
	C6061225R	600	1130	220	H	N/A	25	11099	3250	68.9	92.1	Other Solid Matt RAL	£1,483.50
	C6061225T	600	1130	220	H	N/A	25	11099	3250	68.9	92.1	Metallic Micrograin Matt Paint	£1,661.51
C6061225-W	C6061225W	600	1130	220	H	N/A	25	11099	3250	68.9	92.1	White RAL 9016	£921.43
	C6061632R	600	1440	220	H	N/A	32	14206	4160	88.2	132.6	Other Solid Matt RAL	£2,116.47
	C6061632T	600	1440	220	H	N/A	32	14206	4160	88.2	132.6	Metallic Micrograin Matt Paint	£2,370.45
C6061632-W	C6061632W	600	1440	220	H	N/A	32	14206	4160	88.2	132.6	White RAL 9016	£1,314.58

Addons

Name	Summary	RRP
C6FTR	6 Column Radiator Feet in Other Solid Matt RAL	£98.29
C6FTT	6 Column Radiator Feet in Metallic Micrograin Matt Paint	£110.08
C6FTW	6 Column Radiator Feet in White RAL 9016	£56.16

When ordering suffix the product code with "C" for chrome finish and "w" for with finish etc. Fuel options: E: Electric only H: Hot Water only D: Dual Fuel which is both electric in summer and central heating hot water in winter Prices include delivery. However a delivery charge may be applicable to Scottish Highlands and overseas postcodes.
Prices above are recommended retail prices and are exclusive of any customer duty, levy or value added tax. Pipe centre measurements are incorporating pair of valve distance of 45mm each where applicable. Outputs published are to EN442 at ΔT50. Multiply by 1.268 to convert the outputs to ΔT60.
Prices quoted are guided prices and are subject to change. Product specification is subject to change without prior notification.
E/H/D: The price quoted refers to a product suitable for Hot Water. Electric and Dual Fuel options require additional elements; please contact Ultraheat for a quote.
